Manganese(ll,lll) Oxide
Mn3O4 1317-35-7

Manganese(ll,lll) Oxide Mn3O4 1317-35-7

Manganese(II,III) Oxide is a highly insoluble thermally stable Manganese source, which the chemical compound with formula Mn3O4. As a transition metal oxide, Trimanganese tetraoxide Mn3O can be described as MnO.Mn2O3, which includes two oxidation stages of Mn2+ and Mn3+. It can be used for a variety of applications such as catalysis, electrochromic devices, and other energy storage applications. It is also suitable for glass, optic and ceramic applications.

Manganese(II,III) Oxide

Synonyms Manganese(II) dimanganese(III) oxide, Manganese tetroxide, Manganese oxide, Manganomanganic oxide, Trimanganese tetraoxide, Trimanganese tetroxide
Cas No. 1317-35-7
Chemical formula Mn3O4 , MnO·Mn2O3
Molar mass 228.812 g/mol
Appearance brownish-black powder
Density 4.86 g/cm3
Melting point 1,567 °C (2,853 °F; 1,840 K)
Boiling point 2,847 °C (5,157 °F; 3,120 K)
Solubility in water insoluble
Solubility soluble in HCl
Magnetic susceptibility (χ) +12,400·10−6 cm3/mol



Enterprise Specification for Manganese(II,III) Oxide

Symbol Chemical      Component  Granularity      (μm) Tap Density (g/cm3) Specific Surface Area (m2/g) Magnetic Substance (ppm)
Mn3O4  ≥(%) Mn  ≥(%) Foreign    Mat.    ≤ %
Fe Zn Mg Ca Pb K Na Cu Cl S H2O
UMMO70 97.2 70 0.005 0.001 0.05 0.05 0.01 0.01 0.02 0.0001 0.005 0.15 0.5 D10≥3.0   D50=7.0-11.0   D100≤25.0 ≥2.3 ≤5.0 ≤0.30
UMMO69 95.8 69 0.005 0.001 0.05 0.08 0.01 0.01 0.02 0.0001 0.005 0.35 0.5 D10≥3.0   D50=5.0-10.0   D100≤30.0 ≥2.25 ≤5.0 ≤0.30

We can also customize other specifications, such as manganese assays of 65%, 67%, and 71%.

What is Manganese(II,III) Oxide used for?

Mn3O4 is sometimes used as a starting material in the production of soft ferrites e.g. manganese zinc ferrite, and lithium manganese oxide, used in lithium batteries. Manganese tetroxide can be used as a weighting agent while drilling reservoir sections in oil and gas wells. Manganese(III) Oxide is also used to produce ceramic magnets and semiconductors.
